川消自動跟蹤定位消防水炮安裝步驟以及注意
來源：http://m.xintli.net/ 日期：2022-07-09
自動跟蹤定位消防水炮可全天自動監測保護范圍內的火情。一旦發生火災，滅火裝置會立即啟動，其裝置會在水平和垂直方向智能掃描火源。確定火源的兩個方向后，控制器發出指令，發出火警信號，同時啟動水泵并打開閥門。下面川消來講講自動跟蹤定位消防水炮安裝步驟以及注意事項吧。
The automatic tracking and positioning fire water monitor can automatically monitor the fire within the protection range all day. In case of fire, the fire extinguishing device will start immediately, and its device will intelligently scan the fire source in the horizontal and vertical directions. After determining the two directions of the fire source, the central controller sends a command, sends a fire alarm signal, starts the water pump and opens the valve at the same time. Let's talk about the installation steps and precautions of automatic tracking and positioning fire water monitor.
安裝步驟
Installation steps
1、滅火裝置安裝前應對系統管網進行壓力試驗，試驗合格后進行沖洗；
1. Before the installation of the fire extinguishing device, the pressure test shall be carried out on the system pipe network, and the flushing shall be carried out after the test is qualified;
2、將滅火裝置的上法蘭安裝到短立管的下端，將法蘭端面調整到與水平儀水平；
2. Install the upper flange of the fire extinguishing device to the lower end of the short riser, and adjust the end face of the flange to be level with the level gauge;
3、通過4個配套螺栓固定滅火裝置；
3. Fix the fire extinguishing device with 4 matching bolts;
4、插上電源航空插頭，調整線束長度，保證滅火裝置在轉動范圍內不受限制，并有輕微余量；
4. Plug in the aviation plug of the power supply, adjust the length of the harness, and ensure that the fire extinguishing device is not limited within the rotation range, with a slight margin;
5、每臺自動跟蹤定位消防水炮安裝完成并接線正確后，可用現場手動控制箱進行通電測試，通電即可自動定位（您可在距離滅火裝置500mm處用打火機測試），通過現場手動控制箱。只有在控制箱可以遠程控制后，才能拆除腳手架。
5. After the installation of each automatic tracking and positioning fire water monitor is completed and the wiring is correct, the on-site manual control box can be used for power on test, and then the automatic positioning can be carried out after power on (you can use a lighter to test 500mm away from the fire extinguishing device), and pass the on-site manual control box. The scaffold can be removed only after the control box can be remotely controlled.
安裝注意事項
Installation precautions
1、短立管上必須安裝防搖支架，短路管上防搖支架的固定點與滅火裝置上法蘭的距離不應大于200mm，以保證滅火裝置在旋轉和噴水時不晃動；
1. The anti sway support must be installed on the short riser, and the distance between the fixed point of the anti sway support on the short riser and the flange on the fire extinguishing device should not be greater than 200mm, so as to ensure that the fire extinguishing device will not shake when rotating and spraying water;
2、必須嚴格執行《自動掃描定位噴水滅火系統施工及驗收規范》；
2. The code for construction and acceptance of automatic scanning and positioning sprinkler system must be strictly implemented;
3、系統管網必須進行水壓試驗，各接頭處無滲漏，管網沖洗后必須安裝滅火裝置；
3. The system pipe network must be subject to hydraulic test, and there is no leakage at each joint. Fire extinguishing devices must be installed after the pipe network is flushed;
4、避免強電磁場輻射；
4. Avoid strong electromagnetic field radiation;
5、設備發生故障時，及時按下現場手動控制箱的急停按鈕，切斷電磁閥電源；
5. In case of equipment failure, press the emergency stop button of the on-site manual control box in time to cut off the power supply of the solenoid valve;
6、安裝在舞臺、演播室、也可用于演藝的場所的滅火裝置，在演出、排練時，應將滅火裝置切換到手動狀態或?qū)缁鹧b置的電源接通。關掉;
6. For the fire extinguishing devices installed on the stage, studio and places that can also be used for performing arts, during the performance and rehearsal, the fire extinguishing devices should be switched to the manual state or the power supply of the fire extinguishing devices should be connected. Turn off;
7、現場有電焊、明火作業時，應將滅火裝置切換到手動狀態或關閉滅火裝置電源；
7. When there are electric welding and open fire operations on site, switch the fire extinguishing device to manual state or turn off the power supply of the fire extinguishing device;
8、建議在電磁閥前加裝過濾器，防止因管網雜質導致電磁閥關閉不嚴而漏水；
8. It is recommended to install a filter in front of the solenoid valve to prevent water leakage due to loose closing of the solenoid valve caused by impurities in the pipe network;
9、移動和安裝滅火裝置時，注意保護滅火裝置下方的傳感器，不要將滅火裝置直接放在桌子上或地面上，以免傳感器損壞；
9. When moving and installing the fire extinguishing device, pay attention to protect the sensor under the fire extinguishing device. Do not put the fire extinguishing device directly on the table or the ground to avoid damage to the sensor;
10、
川消小編提醒您，嚴禁對水平機構和垂直（噴嘴）機構施力，以免損壞滅火裝置中的限位開關。
10. Chuanxiao Xiaobian reminds you that it is strictly forbidden to apply force to the horizontal mechanism and vertical (nozzle) mechanism to avoid damaging the limit switch in the fire extinguishing device.
以上就是今天為大家介紹的關于問題以及注意事項的全部?jī)?nèi)容，希望對大家能有所幫助，想要了解更多內容可以電話聯系我們或者關注我們的網站
http://m.xintli.net，我們的工作人員會及時與您取得聯系。
The above is all about the problems and precautions introduced to you today. I hope it can help you. If you want to know more, you can contact us by phone or follow our website http://m.xintli.net , our staff will contact you in time.
