消防軟管卷盤的安裝地方以及使用方法
來源:http://m.xintli.net/ 日期:2022-09-28
消防軟管卷盤主要安裝在酒店、重要辦公樓、商業建筑、會展建筑、綜合樓等。下面為了更好的讓大家了解到該產品,
川消小編為您講講消防軟管卷盤的安裝地方以及使用方法。
The fire hose reel is mainly installed in hotels, important office buildings, commercial buildings, exhibition buildings, complex buildings, etc. In order to better let you know about the product, Chuanxiao Xiaobian will tell you about the installation place and use method of the fire hose reel.
消防軟管卷盤的安裝地方
Installation place of fire hose reel
建筑高度超100米的一類建筑和其他高層建筑。應安裝消防卷盤,其用水量可不計入消防用水總量。消防卷盤之間應有水流,水流可到達室內地面的部分。消防卷盤的安裝高度應便于接近、靈活、無卡澀。
Class I buildings and other high-rise buildings with a building height of more than 100 meters. Fire reel shall be installed, and its water consumption may not be included in the total fire water consumption. There should be water flow between fire reels, and the water flow can reach the indoor ground. The installation height of fire reel shall be easy to access, flexible and free from jamming.
火輪的插頭直徑應為25毫米;配備直徑不小于19mm的膠帶;卷盤的消防噴嘴直徑不小于6.00毫米。“消防軟管卷盤”是一種滅火裝置,由閥門、輸入管、軟管、噴槍等組成。
The plug diameter of the fire wheel shall be 25 mm; Tape with diameter not less than 19mm shall be provided; The fire nozzle diameter of the reel shall not be less than 6.00mm. "Fire hose reel" is a fire extinguishing device, which is composed of valves, input pipes, hoses, spray guns, etc.
并能在迅速展開軟管的過程中噴灑滅火劑。發生火災時,消防人員用它來連接水管滅火。打開柜子,松開消防卷盤,接上水管,打開水閥,滅火。
The fire extinguishing agent can be sprayed during the rapid expansion of the hose. In case of fire, firefighters use it to connect water pipes to extinguish the fire. Open the cabinet, loosen the fire reel, connect the water pipe, open the water valve and extinguish the fire.

消防水帶卷盤又稱消防水帶卷盤,由線圈、軟管和銅矛頭組成。使用時可直接從線圈中抽出,方便易操作,主要用于撲滅初期火災。
Fire hose reel, also known as fire hose reel, is composed of coil, hose and copper spear head. When in use, it can be directly drawn out from the coil, which is easy to operate, and is mainly used to extinguish the initial fire.
一般在一些方便的、容易發生火災的區域周圍的墻上安裝一個紅色的消防柜,周圍一般會有滅火器和火災報警器。
Generally, a red fire cabinet is installed on the wall around some convenient and fire prone areas, and there are usually fire extinguishers and fire alarms around.
消防軟管卷盤的使用方法:
Use method of fire hose reel:
先打開消防栓箱的門,然后將消防自救托盤對準右側,然后解鎖,調整角度。左手握住卷盤的水槍頭,右手握住消火栓箱的門,輕輕拉出水龍帶,然后將水槍頭拉到著火點附近,再用一只手握住水槍頭。另一只手打開球閥噴水,均勻噴灑滅火水覆蓋著火點。
First open the door of the fire hydrant box, then align the fire self rescue tray to the right, then unlock it and adjust the angle. Hold the water gun head of the reel with the left hand, hold the door of the fire hydrant box with the right hand, gently pull out the water hose, then pull the water gun head to the fire point, and then hold the water gun head with one hand. Open the ball valve with the other hand to spray water, and spray fire extinguishing water evenly to cover the ignition point.
確認火源已全熄滅后,關閉水槍閘閥,返回消火栓箱,輕輕轉動水龍帶卷盤,將消防自救卷盤收回消火栓箱內,放置并關閉消火栓箱門,使用完畢。
After confirming that the fire source has been completely extinguished, close the water gun gate valve, return to the fire hydrant box, gently rotate the hose reel, take the fire self rescue reel back to the fire hydrant box, place and close the door of the fire hydrant box, and use it.
消防軟管卷盤一般長度是20m,所用介質一般為水,不適用油類電類的起火。
The fire hose reel is generally 20m long, and the medium used is generally water, which is not suitable for oil and electricity fires.
In the early stage of a fire, the reel can be used. Otherwise, dial 119 to wait for the arrival of the firefighters. Xiao Bian reminds everyone to stay away from fire and cherish life! More relevant content will come to our website http://m.xintli.net Consult!
