川消壓力開關在電氣消防中的具體應用
來源:http://m.xintli.net/ 日期:2022-10-28
壓力開關是一個壓力控制裝置,當被測壓力達到一定壓力值時,壓力開關能發出警報或控制信號。下面
川消小編為您講講壓力開關在電氣消防中的具體應用。
The pressure switch is a pressure control device. When the measured pressure reaches a certain value, the pressure switch can send an alarm or control signal. Now let's talk about the specific application of pressure switch in electrical fire protection.
壓力開關的分類:
Classification of pressure switches:
壓力開關是一種簡單的將系統的壓力信號轉換成電信號的壓力控制裝置,室內消火栓系統中壓力開關的主要功能是將檢測量與設定值相比較,在設定點輸出開關信號,進行報警及聯鎖啟動消防泵。
The pressure switch is a simple pressure control device that converts the pressure signal of the system into an electrical signal. The main function of the pressure switch in the indoor fire hydrant system is to compare the measured value with the set value, output the switch signal at the set point, alarm and interlock the fire pump.
壓力開關主要有機械式和電子式兩大類。
Pressure switches are mainly mechanical and electronic.
機械式壓力開關采用純機械形變導致開關元件動作。當壓力增加時,傳感壓力元器件產生形變,通過欄桿、彈簧等機械結構,啟動開關元件,使電信號輸出。
The mechanical pressure switch uses pure mechanical deformation to cause the switching element to act. When the pressure increases, the sensing pressure components will deform. Through mechanical structures such as railings and springs, the switch components will be started to output electrical signals.

壓力開關的接線:
Wiring of pressure switch:
工作方式:當壓力上升到設定值上限時,藍線和白線斷開,當壓力下降到預先設定的啟泵壓力值時,藍線和白線之間導通。
Working mode: When the pressure rises to the upper limit of the set value, the blue line and the white line are disconnected. When the pressure drops to the preset starting pressure, the blue line and the white line are connected.
1、紅、黑接報警主機的24V電源線,藍、白線接消防控制柜。(藍、白線導通輸出一個無源觸點)。
1. The red and black wires are connected to the 24V power line of the alarm host, and the blue and white wires are connected to the fire control cabinet. (The blue and white lines conduct and output a passive contact).
2、故低壓壓力開共4根線,沒有接線端子可以接輸入模塊,低壓力開關的動作信號無法反饋到主機。(低壓力開關動作可以通過消防泵的啟泵信號反饋給消防主機)。有人可能要問消防泵不能有自動停泵功能,低壓壓力開為什么有個上限值。水規要求零流量時壓力不應大于設計工作壓力的140%,所以只要把壓力開關的上限值調到泵的揚程的1.4倍就可以了。
2. Therefore, there are 4 lines for the low pressure switch. There is no connection terminal to connect the input module. The action signal of the low pressure switch cannot be fed back to the host. (The action of the low pressure switch can be fed back to the fire engine through the pump start signal of the fire pump). Someone may ask why there is an upper limit value for the low pressure switch because the fire pump cannot have the automatic stop function. The water gauge requires that the pressure at zero flow should not be greater than 140% of the design working pressure, so it is only necessary to adjust the upper limit value of the pressure switch to 1.4 times of the pump head.
長期使用要定期檢測它的性能是否完好,如失效或損壞時要由專員進行維修。更多相關事項的了解,就來我們網站
http://m.xintli.net進行咨詢了解吧!
If it is used for a long time, its performance should be checked regularly to see if it is in good condition. If it is invalid or damaged, the specialist should repair it. For more information on related matters, please come to our website http://m.xintli.net Consult and understand!
