細水霧噴頭該如何選擇及布置？
來源：http://m.xintli.net/ 日期：2023-02-13
Selection of Chuanxiao nozzle
1、對于噴頭的噴孔易被外部異物堵塞的場所，應選用具有相應防護措施且不影響細水霧噴放效果的噴頭，如粉塵場所應選用帶防塵罩（端蓋）的噴頭，但在噴霧時不應阻擋水霧和對人員造成的傷害；
1. For places where the nozzle hole is easy to be blocked by external foreign matters, the nozzle with corresponding protective measures that will not affect the spray effect of water mist shall be selected. For dust places, the nozzle with dust cover (end cover) shall be selected, but the water mist and personal injury shall not be blocked during spray;
2、對于電子數據處理機房、通信機房的地板夾層，宜選擇適用于低矮空間的噴頭；
2. For the floor mezzanine of electronic data processing room and communication room, the nozzle suitable for low space should be selected;
3、對于閉式系統，應選擇響應時間指數不大于50(m·s）0.5的噴頭，其公稱動作溫度宜高于環境溫度高溫度30℃，且同一防護區內應采用相同熱敏性能的噴頭；
3. For the closed system, the nozzle with response time index no more than 50 (m · s) 0.5 shall be selected, its nominal operating temperature should be 30 ℃ higher than the ambient temperature, and the nozzle with the same thermal sensitivity should be used in the same protection zone;
4、對于腐蝕性環境，應選用采用防腐材料或具有防腐鍍層的噴頭；
4. For corrosive environment, the nozzle with anti-corrosion materials or anti-corrosion coating shall be selected;
5、對于電氣火災危險場所的細水霧滅火系統，不宜選用撞擊霧化型細水霧噴頭。
5. For the water mist fire extinguishing system in the electrical fire hazard area, the impact atomization water mist nozzle should not be selected.
川消噴頭的布置要求
Layout requirements of Chuanxiao sprinkler
閉式系統的噴頭布置應能保證細水霧噴放均勻并完全覆蓋保護區域；噴頭與墻壁的距離不應大于噴頭大布置間距的1/2；噴頭與其他遮擋物的距離應保證遮擋物不影響噴頭正常噴放細水霧，當無法避免時，應采取補償措施；噴頭的感溫組件與頂棚或梁底的距離不宜小于75mm，且不宜大于150mm。當場所內設置吊頂時，噴頭可貼鄰吊頂布置。
The sprinkler arrangement of the closed system shall ensure that the fine water mist is sprayed evenly and completely covers the protection area; The distance between the nozzle and the wall shall not be greater than 1/2 of the large spacing of the nozzle; The distance between the nozzle and other obstructions shall ensure that the obstructions do not affect the normal spray of fine water mist by the nozzle. When it is unavoidable, compensation measures shall be taken; The distance between the temperature sensing component of the nozzle and the ceiling or beam bottom should not be less than 75mm, and should not be more than 150mm. When the ceiling is set in the site, the sprinkler can be arranged close to the ceiling.
開式系統的噴頭布置與閉式系統的噴頭布置要求相同，但對于電纜隧道或夾層，噴頭宜布置在電纜隧道或夾層的上部，并應能使細水霧完全覆蓋整個電纜或電纜橋架。
The sprinkler arrangement of the open system is the same as that of the closed system, but for the cable tunnel or interlayer, the sprinkler should be arranged at the upper part of the cable tunnel or interlayer, and should be able to completely cover the entire cable or cable bridge with fine water mist.
噴頭布置應能保證細水霧完全包容或覆蓋保護對象或部位，噴頭與保護對象的距離不宜小于0.5m。用于保護室內油浸變壓器時，變壓器高度超過4m的，噴頭宜分層布置；冷卻器距變壓器本體超過0.7m的，應在其間隙內增設噴頭；噴頭不宜直接對準高壓進線套管；變壓器下方設置集油坑的，噴頭布置應能使細水霧完全覆蓋集油坑。
The nozzle arrangement shall ensure that the water mist completely covers or covers the protected object or part, and the distance between the nozzle and the protected object shall not be less than 0.5m. When it is used to protect indoor oil-immersed transformer, if the transformer height exceeds 4m, the nozzle should be arranged in layers; If the distance between the cooler and the transformer body is more than 0.7m, the nozzle shall be added in its gap; The nozzle should not be directly aligned with the high-voltage incoming bushing; If an oil sump is set under the transformer, the nozzle arrangement shall be able to completely cover the oil sump with fine water mist.
系統應按噴頭的型號、規格儲存?zhèn)溆脟婎^，其數量不應小于相同型號、規格噴頭實際設計使用總數的1%，且分別不小于5只。更多相關內容就來我們網站
http://m.xintli.net咨詢！
The system shall store spare sprinklers according to the model and specification of sprinklers. The number of spare sprinklers shall not be less than 1% of the total number of actual designed sprinklers of the same model and specification, and shall not be less than 5. Come to our website for more relevant content http://m.xintli.net consulting service
