消防信號閘閥工作原理與優點
來源：http://m.xintli.net/ 日期：2023-03-23
消防信號彈性閘閥是能顯示和輸出閥門啟閉狀態信號的彈性閘閥，通過在彈性閘閥閥體上加裝通電信號裝置，可以將閥門啟閉的信號傳送消防中心。針對該消防設備，下面
川消小編為您講解更多:
Fire signal elastic gate valve is an elastic gate valve that can display and output valve opening and closing status signals. By installing a power on signal device on the elastic gate valve body, the valve opening and closing signal can be transmitted to the fire center. For this fire-fighting equipment, the following editor of Sichuan Xiaoxiao will explain more to you:
消防信號閘閥工作原理：
Operating principle of fire signal gate valve:
消防信號閘閥采用球墨鑄鐵、不銹鋼、丁腈橡膠等構成，加裝有結構精密的全密封機電信號盒，在閘閥移動到固定位置時，電信號盒回輸出相應的“通”或者“斷”信號。
The fire signal gate valve is composed of ductile iron, stainless steel, nitrile rubber, etc., and is equipped with a fully sealed electromechanical signal box with a precise structure. When the gate valve moves to a fixed position, the electrical signal box outputs the corresponding "on" or "off" signal.
消防信號彈性閘閥優點：
Advantages of fire signal elastic gate valve:
程度高，消防信號彈性閘閥是專門為消防管道系統研發生產的彈性閘閥，在閥門強度、操作方式、耐溫能力等方面都嚴格按照消防閥門生產標準，比其他閥門更適合在消防管道中使用。
High professional level, fire signal elastic gate valve is a flexible gate valve specially developed and produced for fire pipeline systems. It strictly complies with the production standards for fire valves in terms of valve strength, operation mode, temperature resistance, and other aspects, making it more suitable for use in fire pipelines than other valves.
采用無凹槽式閥座設計，使閥門腔室的水流通道趨近直通，不會因為管道中的雜質在凹槽淤積而影響管道的流通性，水流經過閥門時水力損失小，管道的輸水效率有保證。
The non recessed valve seat design allows the water flow path in the valve chamber to approach a straight path, without affecting the flow of the pipeline due to the accumulation of impurities in the groove. When water flows through the valve, the hydraulic loss is small, and the water delivery efficiency of the pipeline is guaranteed.
消防信號彈性閘閥的內外全部用的環氧樹脂進行噴涂，降低閥門零部件在使用過程的的生銹問題，保證閥門運轉的靈活度和消防用水的質量。
The inside and outside of the fire signal elastic gate valve are all coated with non-toxic epoxy resin to reduce the rust problem of valve components during use, ensuring the flexibility of valve operation and the quality of fire water.
閥桿處連續設計三道密封圈，嚴密密封，防止閥桿處漏水，在必要的條件下可以在不切斷水流的情況下進行密封圈的更換，保證持續不斷水。
Three sealing rings are continuously designed at the valve rod to provide a tight seal to prevent water leakage at the valve rod. If necessary, the sealing ring can be replaced without cutting off the water flow to ensure continuous water supply.
選用優良的球墨鑄鐵，利用的工藝，進行閥體的整體鑄造，閥體具有強大的抗擊打能力，使用壽命長。
Using excellent ductile iron and advanced technology, the valve body is integrally cast. The valve body has strong resistance to impact and long service life.
The valve flap has small opening and closing resistance, making it convenient and labor-saving to open and close. At the same time, it can remotely control the opening and closing of the valve, ensuring real-time control of the valve. For more information, please visit our websitehttp://m.xintli.net Consult!
