濕式報警閥的工作事項
來源：http://m.xintli.net/ 日期：2023-05-27
濕式報警閥是一種只允許水流入濕式滅火系統的單向閥，在規定壓力、流量下驅動配套部件報警。火災發生時，閉式噴頭探測火災，受熱開啟滅火；水流經過濕式報警閥組，濕式報警閥啟動，經過延遲器延時后，水力警鈴和壓力開關動作；壓力開關連鎖消防水泵啟動，同時向控制中心發出報警信號。
Wet alarm valve is a one-way valve that only allows water to flow into the wet fire extinguishing system, and drives the supporting components to alarm under the specified pressure and flow rate. When a fire occurs, the closed nozzle detects the fire and starts to extinguish it when heated; The water flows through the wet alarm valve group, and the wet alarm valve is activated. After the delay of the delay device, the hydraulic alarm bell and pressure switch act; The pressure switch interlocks the fire water pump and sends an alarm signal to the control center.
1、
川消濕式報警閥組由閥體、延遲器、水力警鈴、壓力開關、排水閥、過濾器、泄水孔、供水側壓力表、系統側壓力表等組成。閥體被座圈和閥瓣分成上、下兩腔，上腔(系統側)與系統管網相通，下腔(供水側)與水源相通。座圈上有多個溝槽小孔，溝槽小孔與報警水道相通。準工作狀態時，溝槽小孔被閥瓣封閉，水流不能進入報警水道。閥體上設有補償器(類似小孔單向閥)，當系統側管網有微小滲漏或水源壓力有波動時，可以通過補償器平衡閥體的上下腔壓力，避免誤報警。
1. The Chuanxiao wet alarm valve group is composed of a valve body, a delay device, a hydraulic alarm bell, a pressure switch, a drainage valve, a filter, a drain hole, a water supply side pressure gauge, a system side pressure gauge, etc. The valve body is divided into upper and lower chambers by the seat ring and valve disc. The upper chamber (system side) is connected to the system pipe network, and the lower chamber (water supply side) is connected to the water source. There are multiple grooves and small holes on the seat ring, which are connected to the alarm water channel. When in a quasi working state, the small hole in the groove is closed by the valve disc, and water cannot enter the alarm channel. There is a compensator (similar to a small hole one-way valve) on the valve body, which can balance the pressure of the upper and lower chambers of the valve body through the compensator when there is slight leakage in the system side pipeline network or fluctuations in water source pressure, to avoid false alarms.
2、當灑水噴頭開放時，報警閥的系統側壓力降低，水流推動閥瓣開啟，進入系統側管網。同時，水流經溝槽小孔進入報警水道，少部份水流通過泄水孔排放，大部分水流進入延遲器。當延遲器蓄滿以后，水流推動水力警鈴報警，同時壓力開關輸出開關觸點信號，連鎖消防水泵。
2. When the sprinkler head is open, the system side pressure of the alarm valve decreases, and the water flow pushes the valve disc open, entering the system side pipe network. At the same time, the water flows into the alarm channel through the small holes in the groove, with a small portion of the water discharged through the drain hole, and the majority of the water flowing into the delay device. When the delay device is fully charged, the water flow pushes the hydraulic alarm bell to alarm, and at the same time, the pressure switch outputs a switch contact signal to interlock the fire water pump.
注：延遲器可以進一步防止水流波動引起的誤動作，閥瓣誤動以后，會自動復位，在延遲器蓄滿以前，水可以經泄水孔放空。
Note: The delay device can further prevent misoperation caused by water flow fluctuations. After misoperation of the valve disc, it will automatically reset. Before the delay device is fully charged, the water can be discharged through the drain hole.
