川消消防水泵的使用應該了解要點
來源：http://m.xintli.net/ 日期：2022-06-01
1、消防泵應配備備用泵，其性能應與工作泵的性能一致，但以下建筑物可不配備備用泵：建筑高度小于54m的住宅室外消防給水設計流量小于等于25L/s的建筑物，室內消防給水設計流量小于等于10L/s的建筑物。
1. The fire pump shall be equipped with a standby pump whose performance shall be consistent with that of the working pump, but the following buildings may not be equipped with a standby pump: buildings with a building height of less than 54m, buildings with an outdoor fire water supply design flow of less than or equal to 25l/s, and buildings with an indoor fire water supply design flow of less than or equal to 10l/s.
2、消防泵的串聯是將一臺泵的出水口與另一臺泵的吸水管直接相連，兩臺泵同時運行。消防泵串聯可在流量恒定時增加揚程。消防泵并聯是通過兩臺或多臺消防泵同時向消防供水系統供水。消防泵并聯主要是為了增加流量。
2. The series connection of fire pumps is to directly connect the water outlet of one pump with the suction pipe of the other pump, and the two pumps operate at the same time. The fire pump in series can increase the lift when the flow is constant. Parallel connection of fire pumps means that two or more fire pumps supply water to the fire water supply system at the same time. Parallel connection of fire pumps is mainly to increase the flow.
3、川消消防泵直接從市政管網抽水時，應在消防泵的出水管上安裝帶空氣隔板的防回流裝置。當吸水口無吸水井時，應在吸水口安裝防旋流器。
3. When Chuanxiao fire pump directly draws water from the municipal pipe network, an anti backflow device with air baffle shall be installed on the outlet pipe of the fire pump. When there is no suction well at the suction port, an anti cyclone shall be installed at the suction port.
4、消防水池內消防泵吸水管喇叭口的有效水位不小于600mm。使用旋風防噴器時，淹沒深度不應小于200mm。消防泵吸水管上應設置明桿閘閥或帶自鎖裝置的蝶閥，但設置暗桿閥時，應設置開度刻度和標志；當管徑超過DN300時，應設置電動閥。消防泵吸水管通過消防水池時，應采用柔性套管；采用剛性防水套管時，應在泵的吸入管上設置柔性接頭，管徑不大于DN150。
4. The effective water level at the bell mouth of the fire pump suction pipe in the fire pool shall not be less than 600mm. When using cyclone BOP, the submergence depth shall not be less than 200mm. Rising stem gate valve or butterfly valve with self-locking device shall be set on the suction pipe of the fire pump, but when setting the Non rising stem valve, the opening scale and mark shall be set; When the pipe diameter exceeds DN300, an electric valve shall be set. When the suction pipe of the fire pump passes through the fire pool, the flexible sleeve shall be used; When rigid waterproof casing is used, flexible joint shall be set on the suction pipe of the pump, and the pipe diameter shall not be greater than DN150.
5、消防泵出水管上應設置止回閥和升桿閘閥；使用蝶閥時，應配備自鎖裝置；當管徑大于DN300時，應設置電動閥（與進水管相比）。
5. Check valve and rising stem gate valve shall be set on the outlet pipe of fire pump; When using butterfly valve, it shall be equipped with self-locking device; When the pipe diameter is greater than DN300, an electric valve (compared with the water inlet pipe) shall be set.
6、
川消消防泵應能手動和自動啟停，并應保證從收到泵啟動信號到泵正常運行的自動啟動時間不超過2分鐘。消防泵應由消防水泵出水主管上設置的壓力開關、高位消防水箱出水管上的流量開關或壓力等開關信號直接自動啟動。報警閥開關。
6. Chuanxiao fire pump shall be able to start and stop manually and automatically, and the time from receiving the pump start signal to the normal operation of the pump shall not exceed 2 minutes. The fire pump shall be directly and automatically started by the pressure switch set on the main outlet pipe of the fire pump and the flow switch or pressure switch on the outlet pipe of the high-level fire water tank. Alarm valve switch.
7、消防泵在零流量時的壓力不應超過設計工作壓力的140%；當出水量為設計工作流量的150%時，出口壓力不應低于設計工作壓力的65%。消防給水同一泵組內的消防水泵型號應相同，工作泵臺數不超過3臺。
7. The pressure of the fire pump at zero flow shall not exceed 140% of the design working pressure; When the water output is 150% of the design working flow, the outlet pressure shall not be lower than 65% of the design working pressure. The fire water pumps in the same pump set for fire water supply shall have the same model, and the number of working pumps shall not exceed 3.
此外，為適應消防的需要，消防泵應在結構、抗腐蝕性能、機械性能、真空密封性能、連續運轉性能、引水裝置等方面滿足要求，更為詳細的信息您可以關注我們網站
m.xintli.net咨詢了解！
In addition, in order to meet the needs of fire protection, the fire pump should meet the requirements in terms of structure, corrosion resistance, mechanical performance, vacuum sealing performance, continuous operation performance, water diversion device, etc. for more detailed information, you can pay attention to our website www.cx-fire Com consulting!
