川消干式自動報警閥相關的使用安裝調試要求
來源：http://m.xintli.net/ 日期：2022-08-04
川消干式報警閥定義自動噴水滅火系統中的一種控制閥門。它是在其出口側充以壓縮氣體，當氣壓低于某一定值時能使水自動流入噴水系統并進行報警的單向閥。下面認識下該設備吧。
Dry alarm valve defines a control valve in automatic sprinkler system. It is a one-way valve filled with compressed gas at its outlet. When the air pressure is lower than a certain value, it can make water automatically flow into the sprinkler system and give an alarm. Now let's meet the equipment.
干式報警閥的額定工作壓力應不低于1.2MPa。干式報警閥與工作壓力等級較低的設備配裝使用時，允許將閥的進出口接頭按承受較低壓力等級加工，但在閥上須對額定工作壓力做相應的標記.
The rated working pressure of dry alarm valve shall not be less than 1.2MPa. When the dry-type alarm valve is used with equipment with lower working pressure level, it is allowed to process the inlet and outlet joints of the valve according to the lower pressure level, but the rated working pressure must be marked on the valve
閥在關閉位置，閥瓣組件與閥座內緣之間少有3mm的半徑間隙。閥座的環形空間深度不應小于3mm,軸與軸套之間的徑向間隙不應小于0.125mm。閥瓣軸銷與閥體支承端面之間的軸向間隙不應小于0.25mm。
When the valve is in the closed position, there is at least a 3mm radius gap between the disc assembly and the inner edge of the valve seat. The depth of the annular space of the valve seat shall not be less than 3mm, and the radial clearance between the shaft and the shaft sleeve shall not be less than 0.125mm. The axial clearance between the disc shaft pin and the supporting end face of the valve body shall not be less than 0.25mm.
20200810174204_17761.
20200810174204_ seventeen thousand seven hundred and sixty-one
閥體中對閥的開啟起主導作用的任何往復運動的導向零件，在活動件進入固定處的小徑向間隙不應小于0.7mm,閥處于伺應狀態時，活動件與固定件的小徑向間隙不應小于0.125mm。耐腐蝕的閥瓣導套、軸銷、軸承與其他黑色金屬零件之間的間距不應小于3mm。
For any reciprocating guide part in the valve body that plays a leading role in the opening of the valve, the radial clearance between the movable part and the fixed part shall not be less than 0.7mm when the movable part enters the fixed part. When the valve is in the waiting state, the radial clearance between the movable part and the fixed part shall not be less than 0.125mm. The distance between the corrosion-resistant disc guide sleeve, shaft pin, bearing and other ferrous metal parts shall not be less than 3mm.
1、干式報警閥應在系統管網試壓、沖洗合格后進行。
1. The dry-type alarm valve shall be carried out after the pressure test and flushing of the system pipe network are qualified.
2、干式報警閥應設置在無冰凍危險的環境中，要求安裝場所采光充足，采暖良好，有足夠的安裝空間。
2. The dry-type alarm valve should be set in an environment without freezing danger. The installation site is required to have sufficient lighting, good heating and enough installation space.
3、干式報警閥宜設置在及易于操作的地點，閥座法蘭距地面高度宜為1.2m左右。
3. The dry alarm valve should be set in a safe and easy to operate place, and the height of the valve seat flange from the ground should be about 1.2m.
4、將干式報警閥安裝于管網系統之前，應清洗供水管網，保證供水管網干凈、無異物。
4. Before installing the dry alarm valve in the pipe network system, the water supply pipe network should be cleaned to ensure that the water supply pipe network is clean and free of foreign matters.
5、拆下閥蓋、閥蓋密封墊，檢查閥瓣動作是否靈活。確認動作靈活后，裝好閥蓋密封墊和閥蓋。
5. Remove the valve cover and the sealing gasket of the valve cover, and check whether the action of the valve disc is flexible. After confirming that the action is flexible, install the bonnet gasket and bonnet.
6、將干式報警閥安裝在系統中，下端與供水管道相連，上端與系統噴淋管網相連。
6. Install the dry alarm valve in the system, with the lower end connected to the water supply pipeline and the upper end connected to the system spray pipe network.
注意：干式報警閥須直立安裝。建議干式報警閥兩側距墻不小于0.5m，正面距墻不小于1.5m，所有排水口均采取排水措施。更多注意事項額蓼的了解您可以隨時來網站
http://m.xintli.net咨詢。
Note: the dry alarm valve must be installed vertically. It is recommended that the distance from both sides of the dry alarm valve to the wall is not less than 0.5m, and the distance from the front side to the wall is not less than 1.5m. Drainage measures should be taken for all drains. For more information, you can come to the website at any time http://m.xintli.net consulting service
