手抬機動消防泵的使用與維護事項
來源：http://m.xintli.net/ 日期：2023-01-06
手抬機動消防泵組整機由水泵、引水器、汽油或柴油發動機組成，具有引水結構緊湊、輕便等特點。啟動發動機，帶動水泵葉輪高速轉動，通過真空泵真空或者排氣式真空在≦30秒之間把水從進水管引入水泵，通過水泵葉輪的高數轉動產生壓力，再通過水泵出水口排水。下面
川消小編來講講他的使用與維護。
The whole set of hand lift motor driven fire pump is composed of water pump, water diverter, gasoline or diesel engine, which has the characteristics of compact and light water diversion structure. First, start the engine to drive the water pump impeller to rotate at a high speed. Water is introduced into the water pump from the inlet pipe through the vacuum of the vacuum pump or the exhaust type vacuum within ≤ 30 seconds. The pressure is generated by the high number of rotations of the water pump impeller, and then the water is drained through the water pump outlet. Now let's talk about the use and maintenance of Chuanxiao.
一：準備
1： Preparation
我們要檢查機動泵油箱內是否有油，真空泵是否有潤滑油，離心泵下面排水閥的開關是否關閉以及吸水管內密封膠圈是否完好。
We should check whether there is oil in the oil tank of the motor pump, whether there is lubricating oil in the vacuum pump, whether the switch of the drain valve below the centrifugal pump is closed, and whether the sealing rubber ring in the suction pipe is intact.
二：啟動
2： Start
，將電源開關打開（ON的狀態），查看油路開關是否關閉（啟動處于關閉狀態），冷天或者冷機關閉風門開關，稍開油門開關。有力迅速的啟動拉盤，待整機發動平穩后打開油路開關、打開風門開關。
First, turn on the power switch (ON status), check whether the oil circuit switch is closed (the startup is closed), and turn off the throttle switch slightly in cold weather or cold weather. Start the pull plate forcefully and quickly, and open the oil circuit switch and air door switch after the whole machine starts stably.
三：引水
3： Diversion
連接吸水管，查看排水閥是否關閉，關閉出水閥閥門。用力按下引水閥手柄直到真空泵下方排氣口有水霧噴出，推回引水閥手柄打開出水閥閥門開關。
Connect the suction pipe, check whether the drain valve is closed, and close the outlet valve. Press the handle of the water diversion valve firmly until water mist sprays from the exhaust port below the vacuum pump, and push back the handle of the water diversion valve to open the water outlet valve switch.
注意：引水高度不得超過7米，引水時間不能超過30秒（引水時間超過這個固定值就要檢查吸水管管道是否漏氣）
Note: The water diversion height shall not exceed 7m, and the water diversion time shall not exceed 30s (if the water diversion time exceeds this fixed value, check whether the suction pipe leaks)
四：停機
4： Shutdown
我們將油門關怠速狀態，關閉電源開關，關閉油路開關，冷天我們需要將排水閥打開將余水排除然后關閉。
We turn off the throttle to the idle state, turn off the power switch, turn off the oil circuit switch, and in cold weather we need to open the drain valve to drain the residual water and then close it.
五：維護和保養
5： Maintenance
每月應當對機動泵進行一次啟動，每次使用過后對整機各部件進行檢查，檢查汽油、潤滑油是否充足，使用4小時對機動泵機油進行加注（加注的量剛好和口平齊），使用40小時或者每年對機油進行一次更換，使用50小時對火花塞進行更換。
The motor pump shall be started once a month. After each use, all parts of the whole machine shall be checked to see whether the gasoline and lubricating oil are sufficient. The motor pump oil shall be filled (the filling amount is just flush with the mouth) after 4 hours of use. The engine oil shall be replaced after 40 hours of use or once a year, and the spark plug shall be replaced after 50 hours of use.
手抬機動消防泵主要適用于消防部隊、各消防隊、工礦企業、加油站、住宅小區、學校、醫院、機關、倉儲、大型、老城區及農村集鎮等。手抬消防泵還可以用于排澇、抗旱、綠化澆灌、供水和應急災害救援設備。您對該設備有需求可以來我們這里
http://m.xintli.net選購！
The hand-held mobile fire pump is mainly applicable to fire fighting forces, fire brigades, industrial and mining enterprises, gas stations, residential areas, schools, hospitals, institutions, warehouses, large shopping malls, old urban areas and rural market towns. The hand lift fire pump can also be used for flood drainage, drought resistance, greening irrigation, water supply and emergency disaster rescue equipment. You can come to us if you need this equipment http://m.xintli.net choose!
